Double Cylinder Steel Structure Hydraulic Shear

This product is suitable for the demolition of various steel structures. The jaw opening and closing angle is large, easily solving demolition tasks in various scenarios, with 360-degree rotation and flexible cutting metal at multiple angles.

Products

Powerful---Double large-diameter oil cylinders are powerful and can easily cut metal.

Fast speed---The standard acceleration valve can increase the closing speed by 30%-40%.

Low cost---The blade can be used on multiple sides, reducing the cost of use.

Parameter annotation example:

Project	TORB1000-HSG	TORB2000-HSG	TORB3000-HSG	Unit
Suitable For Excavators	15-20	22-26	30-38	t
Length L1	2016	2355	2675	mm
Length L2	1187	1353	1591	mm
Length L3	656	718	812	mm
Weight(about)	1600	2800	4100	kg
Opening And Closing Working Pressure	32-35	32-35	32-35	Mpa
Opening And Closing Work Flow	90-150	150-200	200-250	L/min
Rotating Working Pressure	10-12	10-12	10-12	Mpa
Rotate Workﬂow	30-40	30-40	30-40	L/min
AOpening Width A	700	750	1000	mm
Blade Length B	325+210	350+260	450+310	mm
Shear Force F1	77	112	132	tf
Shear Force F2	112	153	193	tf
